Power HD GTS 3 HV Low Profile Brushless Servo 30kg - 0.055s #GTS-3

Power HD GTS 3 HV Low Profile Brushless Servo - 30kg - 0.055s

The Power HD GTS-3 HV Low Profile Brushless Servo delivers rapid response and strong holding power in a compact case. With up to 30.0 kg-cm of torque and a 0.055 s transit speed at 8.4V, this CNC aluminium, digital brushless unit is designed for high performance and consistent control. Part number HD-GTS-3.

Key Features
- Four-pole brushless motor: high performance, long life-span, heat-resistant and faster response
- HV operation : 6.08.4V DC
- Dual ball bearings for smooth, precise movement
- 7075 + steel gear train for durability
- Supports Power HD program box PG-CB63
- Supports Flysky radio i-BUS2 protocol for servo parameter setup, data logging and warning functions
- Suggested compatibility : high-speed radio modes
   - Noble NB4 Pro : NOR / SR / SFR
   - Futaba : NOR / SR / UR
   - Sanwa : NOR / SHR / SSR / SUR / SXR
- Working frequency : 1520 / 1666 Hz
- Operating temperature : -20 to 60°C
- Max current : 4.0 A
- Low profile case : 41.0 × 20.0 × 29.0 mm; weight: 63 g

Performance Specifications
- Torque @6.0V : 20.0 kg-cm (277.7 oz-in)
- Torque @7.4V : 26.0 kg-cm (361.1 oz-in)
- Torque @8.4V : 30.0 kg-cm (416.6 oz-in)
- Speed @6.0V : 0.083 s
- Speed @7.4V : 0.067 s
- Speed @8.4V : 0.055 s

Construction
- Motor type : Brushless
- Bearing type : Ball bearing ×2
- Gear type : 7075 + steel

Size-conscious installations benefit from the 20 mm low profile height, while the robust gear train and brushless drive offer dependable performance across a wide voltage range. The GTS-3 HV blends speed, torque and control for demanding RC applications.
